Grabo Nemo Classic The Electric Suction Cup
Description
Grabo Nemo Classic Electric Suction Cup
The groundbreaking new way to lift up to 170 kg. The Nemo GRABO makes light work of heavy lifting.
GRABO attaches to almost any flat surface — rough or smooth! GRABO works with glass, drywall, rough and smooth wood, metal, tiles, concrete, landscaping pavers, and more. GRABO even works with diamond plate metal, uneven stone, and patterned surfaces.
Using the Nemo GRABO improves efficiency and safety for you and your team.
How to Use
- Place the GRABO on your material.
- Turn the power button to the ON position then press the green button to activate the vacuum. Your GRABO will create a strong suction as it sticks to the surface.
- Lift your heavy material and smoothly move it into place. For maximum lifting force, keep the vacuum activated while moving material.
- A rubber-protected pressure gauge helps you monitor the vacuum pressure.
- Press the red button to release the pressure.
Lifting Capacity
| Surface | Perpendicular Hold | Parallel Hold |
|---|---|---|
| Glass | 170 kg | 120 kg |
| Ceramic Tiles | 170 kg | 120 kg |
| Metal | 110 kg | 110 kg |
| Plastic | 100 kg | 100 kg |
| Wood | 100 kg | 65 kg |
| Rough Slate | 80 kg | 80 kg |
| Rough Concrete | 80 kg | 80 kg |
| Dry Wall | 75 kg | 65 kg |
Specifications
- Model/SKU: Nemo GRABO / NG-2B-FB
- Battery: 14.8VDC 2600mAh Li-ion
- Rated Power: 16W
- Charger Input Voltage: 100-240VAC 50/60Hz
- Battery Charging Time: ~2 hrs
- Non-Stop Running Time (Full Charge): 1.5 hrs
- Running Cycles (On Full Charge): 900 ON-OFF cycles of 10 seconds
- Stand-by Mode (Charge Hold): 30 days
- Pump Service Life: 100,000+ ON-OFF cycles / 800+ hrs continuous
- Rated Air Flow: 0.7 cfm (20 L/min)
- Maximum Vacuum Rate: 11.6 Psi (0.8 Bar, 80 kPa)
- Maximum Lifting Capacity: 170 kg
- Dimensions: 297 x 181 x 121 mm
- Net Weight (With Battery): 1.6 kg
- Working Temperature: 0–60°C
- Applicable Surface Type: Peak/valley heights less than 3 mm, arc less than 5°
SAFETY WARNING: GRABO uses strong suction power to create a secure seal. To avoid breakage and safety risks, do not attach your GRABO to glass thinner than 6mm.
GRABO is a registered trademark of Nemo Power Tools LTD.
