Grabo Ottovac Electric Suction Cup
Grabo Ottovac Electric Suction Cup
Changing the workday for glaziers. The OTTOVAC moves glass or any flat material with precision.
Portable and more reliable than pump-action suction tools, safely hold glass with the electric pump and release it with the push of a button.
Prevent over-suction and breakage on fragile materials. When the OTTOVAC reaches optimal vacuum suction, an advanced sensor stops the pump. If suction drops below -55 kPa while material is in motion, OTTOVAC steps in to re-engage the vacuum.
OTTOVAC can safely support weights up to 150 kg.
Powered by two high-performance lithium-ion batteries, OTTOVAC is ready for business. Flexible charging: charge your OTTOVAC from anywhere with the simple Type-C USB port. Charge from an electrical outlet, or plug into a power bank or computer on remote job sites.
Key Features
- Advanced automatic sensor — stops pump at optimal vacuum, restarts if suction drops
- Prevents over-suction and breakage on fragile materials
- USB-C charging — charge from outlet, power bank, or computer
- Compact and portable design for glaziers
- Ergonomic design for precision glass handling
Lifting Capacity
| Surface | Perpendicular Hold | Parallel Hold |
|---|---|---|
| Glass | 150 kg | 150 kg |
| Ceramic Tiles | 150 kg | 150 kg |
Specifications
- Model/SKU: OTTOVAC-V1 (OV-V1)
- Battery: Lithium-ion (USB-C rechargeable)
- Working Voltage: 6V
- Rated Power: 6W
- Working Cycle: 1,500 ON-OFF cycles of 10 seconds
- Service Life: >10,000 times, >800 hrs
- Rated Air Flow: 4 L/min
- Maximum Vacuum Rate: -0.7 bar (-70 kPa)
- Maximum Lifting Capacity: 150 kg
- Dimensions: 200 x 200 x 90 mm
- Net Weight (With Battery): 1.2 kg
- Working Temperature: 0–60°C
Accessories manufactured or sold by GRABO®, including third-party accessories, are engineered specifically for GRABO tools and mounting systems. They are not compatible with the DeWalt GRABO.
GRABO is a registered trademark of Nemo Power Tools LTD.
OTTOVAC by GRABO Introduction
OTTOVAC by GRABO 2024 Update
