Thermogroup 7060 1000mm Mounting System for Single Bar Towel Rails
Thermogroup 7060 Mounting System for Single Bar Towel Rails
The Thermorail SRMS mounting system is designed to simplify the process of installing multiple single electric heated towel rails. The mounting system is installed in the wall prior to it being sheeted with the fixing spigots and rail leads installed. The wall is then sheeted and tiled leaving the mounts and cables protruding from the wall as the fixing point of the rails on the right hand side.
Key Features
- Simplifies installation of multiple single bar heated towel rails
- Pre-installed in wall before sheeting
- Includes fixing spigots and rail leads
- Designed for right-hand side mounting
- Professional cable management solution
Dimensions
W110 x H1000 x D10mm
Frequently Asked Questions
Do I need to order a mounting system?
No, the single bar rails have all the parts needed for installation however the mounting system is recommended when installing multiple bars as it makes it easier for the cable management and spacing.
Do I need a mounting system for both sides of the Single Bar Rail?
No, in most applications only one mounting system is required per set of Single Bar Rails. The mounting system is installed on the right-hand side, where the wiring is, to allow for easier pre-wiring and rail spacing. On the left-hand, non-wired side, the rail has a mount which is screwed into the stud, level with the right-hand side.
How to install ThermoSphere 12V DE Towel Bars with a mounting system
- Mounting System
