Grabo Pro Lifter 20 Electric Suction Cup
Grabo Pro Lifter 20 Electric Suction Cup
GRABO® Pro tools offer a smart digital pressure sensor, digital display, and easy-to-use controls for weight and pressure settings. The professional's choice for electric vacuum lifting technology.
GRABO® PRO uses a high-suction pump and a strong seal to prevent the loss of vacuum pressure while you work. Holding up to 170 kg without losing pressure, GRABO® PRO speeds up jobs without sacrificing precision.
Using your GRABO® PRO is easy. Just lay your tool on any flat surface material and press the green button. GRABO® PRO will monitor vacuum pressure while in motion and even restore your pressure automatically.
Key Features
- Smart digital pressure sensor with digital display
- Automatic ON/OFF sensor — shuts the motor OFF at full vacuum, turns it back on if suction drops
- Slimline ergonomic handle for better grip and less fatigue
- Four anchor points for official and third-party attachments
- Works on smooth and rough surfaces — glass, wood, ceramic tile, metal, concrete, stone
- Removable 14.8V 2600mAh Li-Ion battery — charges in 2 hours, lasts 1.5 hours or 900 cycles
- 30 days standby mode
Lifting Capacity
| Surface | Perpendicular Hold | Parallel Hold |
|---|---|---|
| Glass | 170 kg | 120 kg |
| Ceramic Tiles | 170 kg | 120 kg |
| Metal | 110 kg | 110 kg |
| Plastic | 100 kg | 100 kg |
| Wood | 100 kg | 65 kg |
| Rough Slate | 80 kg | 80 kg |
| Rough Concrete | 80 kg | 80 kg |
| Dry Wall | 75 kg | 65 kg |
Specifications
- Model/SKU: GRABO PRO-LIFTER 20 / GP-1Li-FB
- Battery: 14.8VDC 2600mAh Li-ion
- Rated Power: 16W
- Charger Input Voltage: 100-240VAC 50/60Hz
- Battery Charging Time: ~2 hrs
- Non-Stop Running Time (Full Charge): 1.5 hrs
- Running Cycles (On Full Charge): 900 ON-OFF cycles of 10 seconds
- Stand-by Mode (Charge Hold): 30 days
- Pump Service Life: 100,000+ ON-OFF cycles / 800+ hrs continuous
- Rated Air Flow: 0.7 cfm (20 L/min)
- Maximum Vacuum Rate: 11.6 Psi (0.8 Bar, 80 kPa)
- Maximum Lifting Capacity: 170 kg
- Dimensions: 300 x 184 x 121 mm
- Net Weight (With Battery): 1.5 kg
- Working Temperature: 0–60°C
- Applicable Surface Type: Peak/valley heights less than 3 mm, arc less than 5°
- Additional Features: Pump stops automatically at maximum vacuum rate (11.6 Psi / 0.8 Bar)
SAFETY WARNING: GRABO uses strong suction power to create a secure seal. To avoid breakage and safety risks, do not attach your GRABO to glass thinner than 6mm.
GRABO is a registered trademark of Nemo Power Tools LTD.
Grabo Pro Introduction and Demonstration
Introducing the new Grabo Pro-Lifter 20
Grabo Pro Introduction and Demonstration
